QSW-1500-19EF-POE-AC
Unmanaged L2 switch with PoE 802.3af/at support, 1 x 10/100/1000BASE-T port, 16 x 10/100BASE-T PoE ports, 1 x 1000BASE-T\SFP combo port, 2K MAC addresses, built-in power supply, 100-240V AC, dimensions WxDxH (295x195x45 mm)
Description
The QSW-1500 series switches are affordable and high-performance devices designed to improve and expand your network. All switch ports support the auto MDI/MDIX function, allowing you to use any type of network cable to connect to the switch, which makes it possible to use these switches on existing networks without additional upgrades.
The QSW-1500 supports the latest energy-saving technologies. These technologies allow you to significantly reduce energy costs without degrading the quality of the connection, as well as increase network throughput without significantly increasing energy consumption. The device can automatically adjust power consumption depending on the port load, thereby saving electricity and reducing the amount of hydrocarbon consumption.
The QSW-1500 series of switches contains both 10/100 megabit devices and fully gigabit ones. This allows you to flexibly organize a network at an enterprise. Gigabit switches provide high-speed transfer of large files, while switches with 10/100 ports allow you to reduce energy consumption in places where high speeds are not required. QSW-1500 is manufactured with non-blocking switching technology, which allows it to forward and filter packets at the maximum speed of its ports and provide the highest possible throughput. The use of jumbo frames significantly improves and accelerates the transfer of large files. The IEEE 802.3x flow control function for full-duplex mode and the Back Pressure function prevent network connection overload and increase the reliability and stability of the QSW-1500 switches. The QSW-1500 series switches are an ideal choice for upgrading your network, including Gigabit speeds.
Switch models with a PoE attachment have an internal PoE power supply. This technology allows to reduce the costs of installing additional equipment, providing data transmission and power supply via existing Ethernet cables (category 5E). The model range is represented by various models of devices carrying from 4 to 24 PoE ports, which supply from 15.4 W to 25.5 W (PoE+) per port for devices such as wireless access points, VoIP telephony systems, IP video cameras. Using devices with PoE support reduces energy consumption by 75%, increases office efficiency.
The QSW-1500 supports the latest energy-saving technologies. These technologies allow you to significantly reduce energy costs without degrading the quality of the connection, as well as increase network throughput without significantly increasing energy consumption. The device can automatically adjust power consumption depending on the port load, thereby saving electricity and reducing the amount of hydrocarbon consumption.
The QSW-1500 series of switches contains both 10/100 megabit devices and fully gigabit ones. This allows you to flexibly organize a network at an enterprise. Gigabit switches provide high-speed transfer of large files, while switches with 10/100 ports allow you to reduce energy consumption in places where high speeds are not required. QSW-1500 is manufactured with non-blocking switching technology, which allows it to forward and filter packets at the maximum speed of its ports and provide the highest possible throughput. The use of jumbo frames significantly improves and accelerates the transfer of large files. The IEEE 802.3x flow control function for full-duplex mode and the Back Pressure function prevent network connection overload and increase the reliability and stability of the QSW-1500 switches. The QSW-1500 series switches are an ideal choice for upgrading your network, including Gigabit speeds.
Switch models with a PoE attachment have an internal PoE power supply. This technology allows to reduce the costs of installing additional equipment, providing data transmission and power supply via existing Ethernet cables (category 5E). The model range is represented by various models of devices carrying from 4 to 24 PoE ports, which supply from 15.4 W to 25.5 W (PoE+) per port for devices such as wireless access points, VoIP telephony systems, IP video cameras. Using devices with PoE support reduces energy consumption by 75%, increases office efficiency.
Interfaces
| Ports 10/100/1000BASE-T | 1 port |
| Ports 10/100BASE-T PoE | 16 ports |
| Ports combo 1000BASE-T\SFP | 1 port |
Performance
| Switching capacity | 7.2 Gbps |
| MAC address table | 2K |
Functionality
| Switching type | Store and forward |
| Level | L2 |
Power supply
| Voltage, V | 100-240 |
| PoE | yes |
| PoE+ | yes |
| Power adapters | Integrated power supply |
| Power | АС |
Performance specifications
| Working temperature | -10°C~+55°C |
| Humidity | 90% non-condensing |
| Storage temperature | -40°C~+75°C |
Dimensions
| Height, mm | 45 |
| Depth, mm | 195 |
| Width, mm | 295 |
| Weight, kg | 1,6 |
